Scan2CAD is a Windows program that transforms raster images and PDFs into editable CAD formats like DXF, DWG and G-code.
Accurate
Once installed, it is possible to translate elements in images into true vector objects, preserving curvature, arcs, circles, lines and text as modifiable entities. OCR is applied to text so it becomes editable within AutoCAD and other similar apps instead of bitmap pixels. Layer details and object grouping are retained when originating in formats like PDFs.
Moreover, there are tools to prepare raster imagery before conversion. The list includes speckle removal, smoothing, warping, brightness and contrast adjustments, and line thickening. The app can also evaluate photo quality and display corrections when detecting potential conversion inaccuracies. After cleanup, the vectorization process runs more reliably, with fewer manual edits required afterward.
Batch operations
The utility supports batch processing, allowing multiple files or PDF pages to be converted in one operation. This reduces manual repetition and helps streamline workflow in environments with high volume needs. Additionally, there is a scripting interface via a Python API that enables full automation.
Features
- possible to convert images and PDFs to DXF and DWG;
- users can preserve text with OCR and maintain object structure;
- allows to apply accurate scaling and calibration before processing;
- free to download and use;
- compatible with modern Windows versions.
